REG M1 SERIES FLOWMETERSTYLE

Chrome-plated brass body with all brass high-pressure chamber
Internal reseating relief valve protects against over-pressurization
Sintered filter for additional safety and to extend regulator life
Polycarbonate inner and outer tubes provide greater accuracy and durability
15 LPM Oxygen models provide 75 LPM flood minimum

Specifications

Diaphragm Material

Neoprene

Flow Range

1/2 to 15 LPM

Gas Type

Oxygen

Gauge Size

2 in

Includes

Plastic Swivel Hose Barb

Inlet Connection

CGA 870 Yoke

Inlet Pressure [Max]

3000 psi

Outlet Type

DISS 1240

Type

Single-Stage
