Andrews/Boss-Lock Type F Cam and Groove Adapters, 3 in x 3 in (NPT) Male, Brass

Safety release Cam & Groove couplings permit the release of static pressure when disconnecting hose assemblies
Venting system protects operator from being sprayed with hazardous or non-hazardous fluids or solids
Standard Buna-N seal installed

Quantity 10EA/BOX

Specifications

Body Material=Brass
Connection Type=Male/Male
Dia. [Nom]=3 19/32 in
Height [Nom]=4 1/8 in
Male Barb/Hose=3 in
Male Quick=3 in
Male Thread=3 in (NPT)
Measuring System=Imperial
Operating Pressure [Max]=125 psi
Operating Temp. [Max]=+70 F
Shape=Round
Type=Cam & Groove Adapter
Wt.=4.11 lb
