2 in Standard Dry Gauge, 60 psi, ABS, 1/4 in NPT(M), Center Back Mount

Designed to resist the effects of shock, vibration and pulsation
Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement
Can be used for pumps, hydraulic and pneumatic systems, compressors, machine tools
Also for other installations where it is necessary to have a gauge with a non-corrosive movement
All of the gauges supplied by Dixon are designed for long, reliable service under rugged conditions

Quantity 10EA/BOX

Specifications

Accuracy=±3-2-3%
Body Material=ABS
Connection Size [Nom]=1/4 in NPT(M)
Dia. [Nom]=2 in
Display Type=Dial
Lens Material=Polycarbonate
Mounting=Center Back
Operating Pressure [Max]=60 psi
Operating Temp. [Max]=150 F
Operating Temp. [Min]=-40 F
Type=Pressure
Wt.=0.2 lb
