2 in Standard Dry Gauge, 200 psi, ABS, 1/4 in NPT(M)

Designed to resist the effects of shock, vibration and pulsation
Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement
Can be used for pumps, hydraulic and pneumatic systems, compressors, machine tools
Also for other installations where it is necessary to have a gauge with a non-corrosive movement
All of the gauges supplied by Dixon are designed for long, reliable service under rugged conditions

Quantity 1EA

Specifications

Accuracy=±3-2-3%
Body Material=ABS
Connection Size [Nom]=1/4 in NPT(M)
Dia. [Nom]=2 in
Display Type=Dial
Lens Material=Polycarbonate
Mounting=Bottom
Operating Pressure [Max]=200 psi
Operating Temp. [Max]=150 F
Operating Temp. [Min]=-40 F
Type=Pressure
Wt.=0.25 lb
