Brass Liquid Filled Gauges, 0 to 100 psi, 1/4 in NPT(M), Bottom Mount

Designed for long and reliable service under rugged conditions
Typical applications include those on pumps, hydraulic and pneumatic systems, compressors and machine tools
For other installations where it is necessary to have a gauge with a non-corrosive movement
Glycerin filled

Quantity 5EA/BOX

Specifications

Accuracy=1.5%
Body Material=Brass
Case Material=ABS; Brass
Connection Size [Nom]=1/4 in NPT(M)
Connector Type=NPT
Dia. [Nom]=2 1/2 in
Display Type=Dial
Gauge Size=2 1/2 in
Lens Material=Acrylic
Measuring System=Imperial
Mounting=Bottom
Operating Pressure [Max]=100 psi
Operating Temp. [Max]=140 F
Operating Temp. [Min]=0 F
Range 1=0 to 100 psi
Thread Size [Nom]=1/4 in
Type=Pressure
Used With=Compressors; Hydraulic and Pneumatic Systems; Machine Tools; Pumps
Wt.=0.83 lb
