Liquid Filled Gauges, 0 to 30 psi, 1/4 in NPT(M), Center Back Mount

Designed for long and reliable service under rugged conditions
Typical applications include those on pumps, hydraulic and pneumatic systems, compressors and machine tools
For other installations where it is necessary to have a gauge with a non-corrosive movement
Glycerin filled

Quantity 1EA

Specifications

Accuracy=±3-2-3%
Body Material=Stainless Steel
Case Material=Stainless Steel
Color=Black
Connection Size [Nom]=1/4 in NPT(M)
Connector Type=NPT
Dia. [Nom]=2 1/2 in
Display Type=Dial
Gauge Size=2 1/2 in
Lens Material=Polycarbonate
Measuring System=Imperial
Mounting=Center Back
Operating Pressure [Max]=30 psi
Operating Temp. [Max]=150 F
Operating Temp. [Min]=20 F
Range 1=0 to 30 psi
Thread Size [Nom]=1/4 in
Type=Pressure
Used With=Compressors; Hydraulic and Pneumatic Systems; Machine Tools; Pumps
Wt.=0.01 lb
