RM Cartridge Style Manifold Inline Regulators, Oxygen, 0-160 psig

Forged brass regulator body and bonnet
Field replaceable seat cartridge
RM-pressure compensated bonded neoprene seat with broad face nozzle

Quantity 1EA

Specifications

Applications=Industry
Body Material=Forged Brass
Connection Type=1-11-1/2 in NPS RHM (Inlet); 1-11-1/2 in NPS RHF (Outlet)
Diaphragm Material=Neoprene
Diaphragm Size=2 3/4 in
Flow Range=0-160 psig
Gas Type=Oxygen
Gauge Size=2 1/2 in
Height [Nom]=0 in
Inlet Connection=1-11-1/2 in NPS
Inlet Pressure [Max]=3,000 psig
Length [Nom]=0 in
Outlet Connection=1-11-1/2 in NPS RHF
Outlet Pressure [Max]=160 psig
Outlet Pressure [Min]=20 psig
Series=RM
Type=Inline Regulator
Width [Nom]=0 in
Wt.=6.98 lb
