REB Single Stage Regulators, Nitrogen, 1,000 SCFH

Machined brass body resists corrosion and extends service life
Durable neoprene diaphragm to maintain consistent delivery pressure
Dual inlet filters extend regulator service life

Quantity 1EA

Specifications

Applications=Industry; Purging; Testing
Body Material=Brass
Connection Type=9/16 in-18 RHM (Outlet)
Diaphragm Material=Neoprene
Flow Cap. [Max]=1,000 SCFH
Flow Range=1,000 SCFH
Gas Type=Nitrogen
Gauge Size=2 in
Height [Nom]=0 in
Inlet Connection=CGA 580
Inlet Pressure [Max]=3,000 psig
Inlet Type=CGA-580
Length [Nom]=0 in
Outlet Connection=9/16 in-18 RHM
Outlet Pressure [Max]=100 psig
Series=REB
Type=Single Stage Regulator
Width [Nom]=0 in
Wt.=2.34 lb
