RS Single Stage Regulators, Argon, 10,000 SCFH

Machined brass body resists corrosion and extends service life
Plated zinc bonnet
Durable 2 in neoprene diaphragm to maintain consistent delivery pressure

Quantity 1EA

Specifications

Applications=Industry; Laboratory; Welding
Body Material=Brass
Capacities=Medium
Connection Type=1/4 in NPT Female
Diaphragm Material=Neoprene
Diaphragm Size=2 in
Flow Cap. [Max]=10,000 SCFH
Flow Range=10,000 SCFH
Gas Type=Argon
Gauge Size=2 in
Height [Nom]=0 in
Inlet Connection=CGA 346
Inlet Pressure [Max]=3,000 psig
Inlet Type=CGA-346
Length [Nom]=0 in
Outlet Connection=1/4 in NPT Female
Outlet Pressure [Max]=450 psig
Series=RS
Type=Single Stage Regulator
Width [Nom]=0 in
Wt.=3.59 lb
