EDGE Series 2.0 Regulators, Acetylene/Oxygen/Methane/Hydrogen/Carbon Dioxide

Heavy-duty, high-capacity single stage cylinder regulators feature new and improved gauge designs
Larger faced delivery gauge (low pressure) with high contrasted colored face for easy setting
Enhanced color-coded knob designs provide more comfortable operations
Fully enclosed, highly visible modular gauges for more clarity with robust metal gauge guard
Robust seat gives optimum performance
Consistent pressure and flow delivery
High resistance to oxygen related fires
SLAM knob absorbs impact in the event of a cylinder fall

Quantity 1EA

Specifications

Applications=Automotive; Construction; Fabrication; Offshore Oil; Railcars; Repair and Maintenance; Shipbuilding
Body Diam=2.26 in
Color=Black/Red
Connection Type=CGA 510 (Inlet)
Diaphragm Material=Stainless Steel
Diaphragm Size=2 1/2 in
Flow Range=2 - 15 PSIG
Gas Type=Acetylene; Air; Oxygen; Inert Gas; Methane; Hydrogen; Carbon Dioxide; LP Gas
Gauge Size=2 1/2 in
Height [Nom]=4 in
Includes=Screw; Seal
Inlet Connection=CGA 510
Inlet Type=CGA 510
Length [Nom]=6 in
Outlet Connection=9/16 in - 18 LH
Outlet Pressure [Max]=15 psig
Outlet Pressure [Min]=2 psig
Outlet Size=9/16 in
Outlet Type=Left Hand Thread
Overall Length [Nom]=6 in
Series=EDGE 2.0
Thread - TPI or Pitch=9/16 in - 18 LH
Type=Single Stage Regulator
Width [Nom]=4 in
Wt.=4 lb
