EDGE Series 2.0 Regulators, Carbon Dioxide, 150 psig, CGA 320, High

Heavy-duty, high-capacity single stage cylinder regulators feature new and improved gauge designs
Larger faced delivery gauge (low pressure) with high contrasted colored face for easy setting
Enhanced color-coded knob designs provide more comfortable operations
Fully enclosed, highly visible modular gauges for more clarity with robust metal gauge guard
Robust seat gives optimum performance
Consistent pressure and flow delivery
High resistance to oxygen related fires
SLAM knob absorbs impact in the event of a cylinder fall

Quantity 1EA

Specifications

Applications=Automotive; Civil Construction; Heavy Fabrication; Light Fabrication; Offshore Oil; Railcars; Repair and Maintenance; Ship/Barge Building
Capacities=High
Connection Type=CGA 032 (5/8 in - 15 F RH) (Outlet); CGA 320 (Inlet)
Diaphragm Material=Stainless Steel
Gas Type=Carbon Dioxide
Gauge Size=2 1/2 in
Height [Nom]=4 in
Inlet Connection=CGA 320
Inlet Pressure [Max]=150 psig
Length [Nom]=4 in
Outlet Connection=CGA 032 (5/8 in - 15 F RH)
Outlet Pressure [Max]=150 psig
Outlet Pressure [Min]=5 psig
Outlet Size=5/8 in
Packing Type=Pack

Quantity=1 each
Series=EDGE 2.0
Thread - TPI or Pitch=15
Type=Regulator
Used With=Gas Cutting Equipment
Width [Nom]=6 in
Wt.=4 lb
