EDGE Series 2.0 Regulators, Hydrogen, 150 psig, CGA 350

Heavy-duty, high-capacity single stage cylinder regulators feature new and improved gauge designs
Larger faced delivery gauge (low pressure) with high contrasted colored face for easy setting
Enhanced color-coded knob designs provide more comfortable operations
Fully enclosed, highly visible modular gauges for more clarity with robust metal gauge guard
Robust seat gives optimum performance
Consistent pressure and flow delivery
High resistance to oxygen related fires
SLAM knob absorbs impact in the event of a cylinder fall

Quantity 1EA

Specifications

Applications=Industrial and General Fabrication; Light Fabrication; Repair and Maintenance; Structural Steel Fabrication
Capacities=Medium
Connection Type=9/16 in - 18 LH (Outlet); CGA 350 (Inlet)
Gas Type=Hydrogen
Gauge Size=2 in
Height [Nom]=4 in
Inlet Connection=CGA 350
Inlet Pressure [Max]=150 psig
Length [Nom]=4 in
Outlet Connection=9/16 in - 18 LH
Outlet Pressure [Max]=150 psig
Outlet Pressure [Min]=0 psig
Outlet Size=9/16 in
Packing Type=Pack

Quantity=1 each
Series=EDGE 2.0
Thread - TPI or Pitch=18
Type=Regulator
Used With=Gas Cutting Equipment
Width [Nom]=6 in
Wt.=4 lb
