EDGE Series 2.0 Regulators, Air, Carbon Dioxide, 80 CFH, CGA 320

Heavy-duty, high-capacity single stage cylinder regulators feature new and improved gauge designs
Larger faced delivery gauge (low pressure) with high contrasted colored face for easy setting
Enhanced color-coded knob designs provide more comfortable operations
Fully enclosed, highly visible modular gauges for more clarity with robust metal gauge guard
Robust seat gives optimum performance
Consistent pressure and flow delivery
High resistance to oxygen related fires
SLAM knob absorbs impact in the event of a cylinder fall

Quantity 1EA

Specifications

Applications=Industrial and General Fabrication; Light Fabrication; Repair and Maintenance; Structural Steel Fabrication
Capacities=Medium
Connection Type=CGA 033 (5/8 in - 18 F LH) (Outlet); CGA 320 (Inlet)
Gas Type=Air; Carbon Dioxide
Gauge Size=2 in
Height [Nom]=4 in
Inlet Connection=CGA 320
Inlet Pressure [Max]=80 CFH
Length [Nom]=4 in
Outlet Connection=CGA 033 (5/8 in - 18 F LH)
Outlet Pressure [Max]=80 CFH
Outlet Pressure [Min]=0 CFH
Outlet Size=5/8 in
Packing Type=Pack

Quantity=1 each
Series=EDGE 2.0
Thread - TPI or Pitch=18
Type=Regulator
Used With=Gas Cutting Equipment
Width [Nom]=6 in
Wt.=4 lb
