HSR Regulator/Flowmeter Combinations, Inert Gas, CGA 580, 3,000 psig inlet

MIG/TIG applications
Stem type seat mechanism
External self reseating relief valve (Not designed to protect downstream apparatus)
Accurate regulator for gas flow

Quantity 1EA

Specifications

Body Material=Forged Brass
Depth [Nom]=4 1/4 in
Filter Material=Sintered
Flow Range=5 - 50 Argon; 5 - 40 Argon/CO2; 15 - 20 Helium
Gas Type=Inert Gas
Gauge Size=2 in
Height [Nom]=6 1/4 in
Inlet Connection=CGA 580
Inlet Pressure [Max]=3,000 psig
Outlet Connection=5/8 in - 18 RH(F)
Width [Nom]=7 in
Wt.=3.03 lb
