Heavy Duty Nozzles, 1/8" Tip Recess, 3/4", For Part Nos. HD54-16,HD54-14,HD54-EL

Used in heavy duty welding application up to 450 amperes
Nozzle housing is cut and Formed from 122 DHP copper alloy tubing
Nozzle insert is machined from a solid brass allow and is crimped in place to allow the nozzle to slide over a metal spring which is part of the gas diffuser
Nozzle insulator is made from G7 silicone material, providing the electrical insulation needed from the gas diffuser
Part No. rolled stamped on the outside surface for easy identification
3-piece design does not require an additional insulator

Quantity 1EA

Specifications

Bore Size=3/4 in
Length [Nom]=3.21 in
Material=122 DHP Copper Alloy
Nozzle Style=1/8" Tip Recess
Overall Length [Nom]=3.21 in
Used With=Part No. HD54-16 (Stock No. 1540-1136); Part No. HD54-14 (Stock No. 1540-1135); Part No. HD54-EL (Stock No. 1540-1137)
Width [Nom]=7/8 in
Wt.=0.22 lb
