2 1/2 in Replacement Gauges, 30 psi, Brass, 1/4 NPT, Bottom

One-piece threaded polycarbonate lens
Cupped aluminum dial with white background and red and/or black markings

Quantity 1EA

Specifications

Accuracy=3%-2%-3% per ANSI B40.1 grade B
Body Material=Brass
Case Material=Brass
Connection Size [Nom]=1/4 in NPT
Dia. [Nom]=2 1/2 in
Display Type=Dial
Gauge Size=2 1/2 in
Lens Material=Polycarbonate
Material=Brass
Measuring System=PSI
Mounting=Bottom
Operating Pressure [Max]=30 psi
Pressure [Nom]=30 psi
Thread Size [Nom]=1/4 in (NPT)
Type=Red Line Gauge
Used With=Flowmeters; Regulators
Wt.=0.4 lb
